WISI OE01

Standalone HDMI Modulator

HDMI input, RF output with supporting: DVB-T, DVB-C, DTMB and ATSC

1 RF input, to by-pass terrestrial signals

Easy to control with only one button

Accept wide range of resolution from 576i to 1080p60

Space-efficient

General Data

Power

  • Input Voltage: 12 VDC

  • Consumption: 5 W Typ. (6 W max.)

  • Jack Ø 2.1 mm

Dimension , weight, EAN code

  • 155 x 120 x 60 mm

  • 0.6 kg

  • 2082010000018 or 2082020000015

Accessories

  • 12 V power adapter

Rotary/Push button

Power Supply socket

+ LED indication

Demo

Diagram

CCTV 4

HDMI

connector

Bypass IN

connector

RF out

connector

CCTV 3

CCTV 2

CCTV 1

Digital Video Recorder

1

2

3

4

TechnicalData

HDMI Input

Output Settings

Video resolution

576i up to 1080p

Output type

DVB-T

DVB-C

ATSC-T

ATSC-C

DTMB

Video encoding

H264/AVC

Bitrate (Mbps)

2 - 23

2 - 23

2 - 15

2 - 23

2 - 23

Audio encoding

MPEG1 Layer II / AAC

Channel bandwidth

(MHz)

6,7 or 8

2 - 8

6

8

8

Connector type

HDMI Type A

COFDM

(QPSK/ 16QAM/

64QAM)

16, 32,64,128

256 QAM

QPSK,16,32

,64 QAM

QAM-4NR,

Constellation

8VSB

64, 256QAM

Other settings

Code rate

Guard Interval

2K-8K

-

-

-

Interleave Code rate 2K-8K Sync frame PN phase

RF Input

Video resolution

5 - 1218 Mhz

Loss to RF output

2 dB

RF Output

(=RF Input signal + HDMI modulated transponder)

Modulated channel frequency

174-1218 MHz

Output level

59-99 dBμV

(adjustable)
